|Name:||Bus Led Display||Pixed Pitch:||5mm|
|LED Type:||SMD2727||Display Size:||1600*320mm|
|Ave.Power（≤W/ Set）:||120w||Cabinet Weight:||18KG/PCS|
custom design board led bus display,
smd 2727 led bus display,
3g bus led display board
Custom Design P5 Bus LED Screen High Brightness LEDs For Outdoor Advertising
Bus LED Screen is the new and innovative way to increase revenues through mobility-based advertising, intelligent release and real-time data viewing platform. Our screens enable advertisers to reach their audience via the streets of the city, providing a platform for dynamic content to attract more advertising impressions and get higher conversions. Car advertising is a marketing alternative that is undervalued and underutilized. Seize the opportunity and together make the future of DOOH with 3U View!
1. Muti-connection mode group control, you can choose 3G, 4G or WiFi to control the screen.
2. The supporting software is easy to operate.
3. Quick easy installation and maintenance.
4. Made of outdoor high brightness LEDs and low power consumption.
|Pixel Pitch||5mm||Cabinet Material||Iron|
|Display Size||1600*320mm||Cabinet Color||Black|
|Module Size||320*160mm||Cabinet Weight||18KG/PCS|
|Screen Resolution||320*64||Viewing Angle||120°/120°|
|Module Resolution||64*32||Refresh Rate||1920Hz|
|Cabinet Size||1630*325*65||Brightness||4500 cd/m2|
|Max. Power (≤W/ set)||400W||Driving Method||1/8|
|Ave. Power (≤W/ set)||120W||Supported Formats||JPG,GIF ,BMP, WMF,MP4|
|Input Voltage||24V||Screen lifespan||＞100000 hours|
|Output Voltage||5V||Environmental Requirements||
Temperature: - 40℃ ~ + 80 ℃
Humidity: 10% ~ 95% RH
Q: What brand of lamp beads do you use?
A: We use the Guoxing encapsulated lamp beads, if you have requirements on the lamp beads, we can also accept customization.
Q: How to reduce the temperature of Bus LED Screen?
A: The screen is integrated with a temperature controlled fan. When the temperature inside the screen reaches above 40 degrees, the fan will start automatically to lower the operating temperature inside the screen.
Q: How does the screen adjusts its brightness?
A: Our Bus LED Display isn’t equipped with a light sensor because it is installed inside the bus. But if you have a need, we can customize for you.
Q: What protections does screen has for power supply?
A: Our power supply is specially customized for the Car LED Screen, in addition to the normal short circuit protection, over current protection, over voltage protection, reverse polarity protection and delay start function, which can well protect the car battery and other electronic equipment.
Q: Why is your screen starting so slowly?
A: In order to protect the battery and other electronic equipment on the car, we adopt the delay start function to avoid the impact of the instantaneous current on other electronic equipment.
Introduction to control system
Advertising cluster control system is a special system for LED advertising media. The use of LED advertising media cluster release system can perfectly realize bus advertising screen cluster control and advertising release. The system client integrates the functions of online remote management and advertisement arrangement and publishing of multi-user and multi terminal. It integrated 4G wireless internet access mode, and is integrated design, so it can access the Internet without any external equipment.
Bus LED Screen Case
